商品の詳細:
|
| 秤交換: | ロックウェル 表面的な ロックウェル | 休憩 時間: | 0-60s |
|---|---|---|---|
| ロックウェルの総負荷: | 60kgf (588.4N) 100kgf (980.7N) 150kgf (1471N) | 表面ロックウェルの総負荷: | 15kgf (147.1N) 30kgf (294.2N) 45kgf (441.3N) |
| 負荷値の誤り: | 0.5%未満 | 硬度測定の精度: | 0.5HR |
| サンプルの最大高さ: | 220mm | 外壁への圧子の間隔: | 200mm |
| ハイライト: | touch screen Rockwell hardness tester,Rockwell hardness tester 15 scales,non-destructive testing hardness tester |
||
| Exchanging scales | Rockwell, Superficial Rockwell |
| Dwell time | 0-60s |
| Total load of Rockwell | 60kgf (588.4N) 100kgf (980.7N) 150kgf (1471N) |
| Total load of Superficial Rockwell | 15kgf (147.1N) 30kgf (294.2N) 45kgf (441.3N) |
| Load value error | Less than 0.5% |
| Hardness measurement accuracy | 0.5HR |
| Max Height of Sample | 220mm |
| Distance of Indenter to outer wall | 200mm |
Industrial production, Inspection of product quality on processing technology. Ferrous and nonferrous metals, Hardened steel, tempered steel, annealed steel, hardened steel, sheet of various thicknesses, carbide materials, powder metallurgy materials, hardness and thermal spray coating.
Sheet metal, thin-walled pipe, hardened steel, and small parts of hardness.
Widely used in machinery manufacturing, metallurgy plants, universities, laboratories, etc.
| Product model | HR-150DX |
| Scales Converted to | Rockwell, Brinell, Vickers |
| Dwell time | 0-60s |
| Initial load of Rockwell | 10kgf (98N) |
| Total load of Rockwell | 60kgf (588.4N) 100kgf (980.7N) 150kgf (1471N) |
| Initial load of Superficial Rockwell | 3kgf (29.4N) |
| Total load of Superficial Rockwell | 15kgf (147.1N) 30kgf (294.2N) 45kgf (441.3N) |
| Load value error | 0.5% |
| Hardness testing range | HRA: 20-96 HRB: 20-100 HRC: 20-70 HRD: 40-77 HRE: 70-100 HRF: 60-100 HRG: 30-94 HRH: 80-100HRK: 40-100HRL: 50-115HRM: 50-115 HRR: 50-115 |
| Testing rage of Superficial Rockwell | HR15N: 70-94; HR30N: 42-86; HR45N: 20-77; HR15T: 67-93; HR30T: 29-82; HR45T: 10-72 |
| Hardness measurement accuracy | 0.5HR |
| Executive standard | GB/T230.1 GB/T230.2 national standard JJG112 verification regulation |
| Max Height of Sample | 220mm |
| Distance of Indenter to outer wall | 200mm |
| Hardness reading | LCD display |
| Data output | USB flash disk |
| Power supply | AC220V,50/60HZ |
| Net weight | About 70kg |
| Name | Quantity | Name | Quantity |
|---|---|---|---|
| Diamond Rockwell indenter | 1 | Ball indenter with the diameter of 1.5875 mm | 1 |
| Hardness block (HRB, HRC high, HRC low value) | 3 | Large, medium, V-type testing table | 1 for each |
| Power line | 1 | Dustproof plastic housing | 1 |
| USB flash disk | 1 | Operating Instruction, Product Qualification Certificate | 1 for each |
